High Strong Duct Rodder/ Electric Cable Duct Rod

  • High Strong Duct Rodder/ Electric Cable Duct Rod
  • High Strong Duct Rodder/ Electric Cable Duct Rod
  • High Strong Duct Rodder/ Electric Cable Duct Rod
  • High Strong Duct Rodder/ Electric Cable Duct Rod

High Strong Duct Rodder/ Electric Cable Duct Rod

    Payment Type: L/C,T/T,Paypal,Money Gram,Western Union
    Terms of Trade: FOB,CFR,CIF
    Min. Order: 3 Set/Sets
    Delivery Time: 10 Days
    Packaging: Carton box or crate
    Productivity: 5000 sets/month
    Brand: Long Zhuo
    Transportation: Ocean,Land,Air
    Place of Origin: China Mainland
    Supply Ability: 10 Production Lines
    Certificate: ISO
    Port: Tianjin

Basic Info

Model No.: FDR

Product Description

High Strong Duct Rodder/ Electric Cable Duct Rod



Features of High Strong Duct Rodder/ Electric Cable Duct Rod

  1. Constructed of fiberglass reinforced in the center and consists of a rugged plastic layer that would ensure the lifetime of the flexible rod.
  2. Assembly: metal frame and rubber wheels, Wheel assembly for easy transportation; Guide rollers and the right parts for rotary coupling; parking brake for the flexible rod.
  3. There is copper wire inside for tracing easily.
  4. Polyethylene cover: Medium density polyethylene resin for the insulating and jacketing of cables.
  5. Rolling bearing cage flotation (reel transport) for mobility should be light and easy to use in the field, including a parking brake for the flexible rod.
  6. Feed device allows rod to feed out or be back with easy push or pull of rod
  7. Rugged tubular steel reel with adjustable positioning
  8. Rustproof bull-nose pulling eye for longer conduit run and underground duct
  9. Constructed of fiberglass reinforced in the center and consists of a rugged plastic layer that would ensure the lifetime of the flexible rod

Quality Control

We have the complete production equipments and professional production team to manage the whole process from production to packing shipment.All products will 100% test before delivery to ensure the quality.



Application

1.Used to install pulling ropes and winch ropes into ducts,ready for cable pulling operations.

2.Fiberglass rod is lightweight and flexible.

3.Dia of duct rod:4mm;6mm;8mm;9mm;10mm;11mm;12mm;13mm;14mm;15mm;16mm
4.Length of pulling rod:50m/100m/ 150m/ 200m/300m;

Technial Data of High Strong Duct Rodder/ Electric Cable Duct Rod

Specification

Rod Diameter (mm)

Φ4,Φ4.5,Φ5,Φ6,Φ8,Φ10,Φ11,Φ12,Φ13,Φ14,Φ15,Φ16

Rod Length (m)

50~500

Frame Spec.(mm)

1300x450x1330,1200x420x1220,980x350x1000,680x240x700, etc

Wheel Diameter(mm)

300mm

Wall thickness of Metal Frame

2.2mm

Color

blue, yellow, red, white etc

Material

Rod Inner

Extruded by fiber glass and high strength resin at high temperature

Rod Outer

High Density polyethylene coating

Iron Frame

Steel with high-temperature sprayed plastic or Spray coating

Wheel

rubber

Brake

Yes

Drawing head

copper

Physical Characters

Density

55g/m

Working temperature

-40°C to +80°C

Breaking tension

100kg

Bending Radius

295mm

Technology

Pultrusion

Packaging

Inside

plastic woven strip wind around the frame

Outside

Wooden pallet and Wooden box


Fiberglass Duct Rodder Drawing Pictures:


Duct Rodder 2




Fiberglass Duct Rodder Picture Show:

Duct Rodder 3

Fiberglass Duct Rodder Work Shop:

Duct Rodder 5
